Grey High Speed Cat5e FTP Cable 24AWG Aluminum Foil Shield
Specifications:
1. Center Conductor: 0.51±0.01mm BC/CCA
2. Insulationi:0.89±0.02mm PE
3. Shield: Aluminum Foil
4. Drain Wire: 7X0.22±0.01mmTC
5. Mylar:Yes
6. Pair:4
7. Jacket:6.5±0.05mm PVC
8. Ripcord:Yes
9. Comply with the UL requirements
10. We can produce network cable as per customer's request.
11. Pin assignment for RJ45 plug according to T568B wiring scheme.
12. Wirde range of Cord colors for selection according to meet different color coding requirement , in compliant with EIA/TIA 606 standard.
13. Cable color: Blue/Green/Yellow/Black/Gray/Red/White/Purple
Applications:
1. Connect the router and computer
2. Connect the computer and displayer.
3. Mainly Used in the Building Correspondence Synthesis Wiring System the Work Area
Correspondence Leadingout Terminal and between the Connection Distribution Frame Wiring
4. Ues in telecom business.
5. Use in Building.
Description:
24AWG solid bare copper or CCA conductors, over all aluminum foil shield, Polyolefin insulation, twisted pairs, ripcord, drain wire, PVC jacket (red, orange, yellow, green, white, blue or gray)
Suitable Applications: Premise Horizontal Cabel, Gigabit Ethernet, 100 BaseTX, 100BaseVG ANYLAN, 155ATM, 622ATM, NTSC/PAL Component or Composite Video, AES/EBU, Digital Video.
Why choose us?
1. Professional manufacturer: Professional in making various cables.
2. Strictly conform to CE,ROHS,ISO certificate
3. Well-trained and experienced staffs to answer all your inquires in fluent English.
4. Distributorship are offered for your unique design and some our current models.
5. Your inquiry related to our products or prices will be replied in 24 hours.
