Green Lan Cable Ethernet CAT6 UTP Cable Cat 6 Plenum Rated Cable

Name: Green Lan Cable Ethernet CAT6 UTP Cable Cat 6 Plenum Rated Cable
Brand: WONTERM
Price: 1 USD

Brand Name : WONTERM

Model Number : WT6803

Certification : CE/FCC/UL/ROHS

Place of Origin : China

MOQ : 30pcs

Price : negotiation

Payment Terms : T/T or western Union

Supply Ability : 2500pcs per month

Delivery Time : 10 working days after received your payment

Packaging Details : First packed in box and then put two boxes in one Carton.

Number of Conductors : 8

Application : Indoor

Length : 1000ft

Packaging : 2 boxes/carton

Carton CBM(mm) : 48*43*43

temperature range : -40degree-70degree

Contact Now

Green Lan Cable Ethernet CAT6 UTP Cable Cat 6 Plenum Rated Cable

Specifications:

1. Fast and reliable connection
2. Twisted pairs with bright color for easy recognition
3. resistance:(f=1-100MHZ)100±15%
4. delay deviation:(max)40ns/100m
5. rated transmission rate:(NVP):72%
6. tensile resistance:(max)250N
7. temperature range:-40°C~+70°C
8. Color Code: Pair 1: white/blue-blue/white Pair 2: white/orange-orange/white
Pair 3: white/green-green/white Pair 4: white/brown-brown/whiteor as per customer's requirements
9. OEM and ODM
10. Sample available

Green Lan Cable Ethernet CAT6 UTP Cable Cat 6 Plenum Rated Cable

Description:

Model Indoor Cat6 UTP Network. Cable
Conductor Material :Copper/CCA
Conductor Dimension :0.511mm 24AWG /0.404 26AWG
insulation thickness :0.18mm
The thickness of Jacket :0.55mm
Outer Diameter :5.4mm/5mm
Insulation HD-PE (High density polyethylene)
Number of Twisted Pair: 4P
Ripcord :Yes
Jacket PVC (Polyvinyl-Chloride) or LSZH (Low Smoke Zero Halogen)
Color different color is available

Applications:

Green Lan Cable Ethernet CAT6 UTP Cable Cat 6 Plenum Rated Cable
