High Performance Data Category 6 Lan Cable Cat6 Gigabit Cable

Name: High Performance Data Category 6 Lan Cable Cat6 Gigabit Cable
Brand: WONTERM
Price: 1 USD

Brand Name : WONTERM

Model Number : WT6803-F

Certification : CE/FCC/UL/ROHS

Place of Origin : China

MOQ : 30pcs

Price : negotiation

Payment Terms : T/T or western Union

Supply Ability : 2500pcs per month

Delivery Time : 10 working days after received your payment

Packaging Details : First packed in box and then put two boxes in one carton.

Nominal Outer Diameter : 7.3mm

Pairs : 4

Jacket : PVC(LSZH)

Number of Conductors : 8

Packaging : 2 boxes/carton

AWG : 23AWG

Contact Now

High Performance Data Category 6 Lan Cable Cat6 Gigabit Cable

Specifications:

Mode	FTP cat6 lan cable
Conductor Size	28AWG,26AWG,24AWG,23AWG,22AWG
Conductor Material	BC/CCA/CCS/CCAM/CCAG or customized
No.of Conductor	4P
Insulation Material	PE & HDPE
Jacket	PVC, ROHS PVC, LSZH PVC
Shield	Unshielded twisted pairs
Indoor/Outdoor	Single Jacket
Insulation Thickness	0.2mm
Jacket Thickness	0.92-0.95mm
Stretching Resistance	(max)250N
Impedance	100±15%Ω at 1~100MHz
Working Capacitance(Max)	5.4nF/100m
Mainly Application	1.Computer network cabling Project
	2.Broadband Network Communication
	3.Digital ISDN Network and ATM 155Mbps Network
	4.Ethernet Network
	5.Audio and data transmission

High Performance Data Category 6 Lan Cable Cat6 Gigabit Cable

Description:

1, Operating Temperature:-40 °C - +70 °C

2, Transmission Velocity:72%

3, Insulation Resistance:10000MΩ.km

4. DC Resistance Imbalance:2.50%

5. Comply with the UL requirements

6. Filler:PE cross

Applications:

Competitive Advantage:

Our company specializes in producing conductors, utp cables, medium/high-pressure cables, pvc/xlpe cables, YC cable, BV cable, aerial insulation cable and coexial cable. Besides, we offer the most efficient and effective assembly services.
