White Shielded Cat5e Keystone Jack Utp Connector Module Without Panel Stops

Name: White Shielded Cat5e Keystone Jack Utp Connector Module Without Panel Stops
Brand: WONTERM
Price: 1 USD

Wholesale White Shielded Cat5e Keystone Jack Utp Connector Module Without Panel Stops from china suppliers

Brand Name : WONTERM

Model Number : WTKJ

Certification : CE/FCC/UL/ROHS

Place of Origin : China

MOQ : 1000pcs

Price : negotiation

Payment Terms : T/T or western Union

Supply Ability : 30000pcs per month

Delivery Time : 10 working days after received your payment

Packaging Details : 250m/box

HS Code : 8517709000

Gold Plated : 6μ

Installation Mode : Rotary Jack

Shape : Rectangular

Color : White

Delivery Detail : 3 days

Material : Plastic,Gold

Contact Now

8P8C shielded cat5e keystone jack rj45 cat6 wall jack male utp Connector Module

Specifications:

Brand	WONTERM
Certification	CE /UL/FCC/Reach/RoHS
Connector Style	Jack
Connector Type	Modular Jack
Latch	Up
LED Option	Without LED
Panel Stops	Without Panel Stops
Applies To	Printed Circuit Board
Grounding Options	Panel Ground and PCB Ground
Number of Positions	10
Terminals per Port	8
PCB Mounting Orientation	Side Entry (Right Angle)
Contact Base Material	Phosphor Bronze
PCB Mounting Style	Through Hole
Board Lock	Without Board Lock
Housing Color	Black
UL Flammability Rating	UL 94V-0

Product Description:

1. Convert your standard 1:1patch cable into a crossover cable by connecting it to this adapter.
2. Connectors: RJ-45 Plugs, 50u Gold-plated

3. Housing: high temperature thermoplastic

4. Available in Cat6, T568A/B wiring, meet or exceed TIA/EIA Cat6 requirements.

3. Compact jack design, 8 positions and 8 conductors

4. Contact: phosphor bronze, phosphor bronze with 6 to 50u” gold plate

5. Accept 22-26AWG solid with a insulation diameter of 0.4-0.6 mm

Mechanical characteristics

Description	Description
Contract resistance(max)	100mΩ
Insulation resistance (min)	500mΩ
Return loss (dB)	5.8(dB)
next(dB)	4.7(dB)
Ps next(dB)	5.5(dB)

Application

1. Available in different color
2. High reliability and superior performance
3. Easy to be terminated, extremely low attenuation loss
4. Electrical data: according to UL 1863
5. Card access repetitions> 250 times
6. The socket mating cycles ≥ 750 times
7. Contact pin plating thickness> 50U

White Shielded Cat5e Keystone Jack Utp Connector Module Without Panel Stops

Product Tags:

network keystone jack

utp keystone jack

White Shielded Cat5e Keystone Jack Utp Connector Module Without Panel Stops Images
